87792 ERA Heavy-Duty Trailer Wheel Rim (13×4.5, 14×5.5, 14×6 ET0) – PCD 4×100, 5×114.3, 6×139.7 Steel Wheel Wholesale
Commercial-Grade ERA Zero-Offset (ET 0) Steel Trailer Wheels in 13" and 14" Configurations with Multi-PCD and Center Bore Options for Caravans, Boat Trailers & Utility Rigs | Direct Factory OEM & Bulk Supply
| Technical Specification | Parameters & Engineering Details |
| Brand Name | ERA |
| Product Type | Heavy-Duty Trailer Wheel Rim (Stamped Structural Steel) |
| Available Rim Sizes | 13 × 4.5, 14 × 5.5, 14 × 6 |
| Pitch Circle Diameter (PCD) | 4 × 100mm, 5 × 114.3mm (5 on 4.5″), 6 × 139.7mm (6 on 5.5″) |
| Center Bore (CB) Options | 73mm, 81.5mm, 83.7mm, 108.7mm |
| Wheel Offset (ET) | ET 0 (True Zero Offset for Balanced Hub Load Distribution) |
| Rim Style Options | Modular Hole, Classic 8-Spoke, or Solid Disc Profile |
| Material Construction | High-Yield Heavy-Gauge Structural Carbon Steel |
| Surface Protection | Hot-Dip Galvanized, Commercial White Powder Coat, or Satin Black E-Coat |
| Highway Certification | DOT & SAE J1204 Compliance for High-Speed Highway Towing |
| Target Applications | Marine Boat Trailers, Caravans, Camper Trailers, Box Utility Haulers, Horse Floats |
| B2B Supply Capabilities | Custom PCD Drilling, Stamped Customer Logo, Matched Valve Stems, Pallet Export Packaging |
Key Features
True Zero Offset (ET 0) Engineering: Distributes axle vertical load directly over hub bearings, eliminating abnormal spindle leverage, uneven tire wear, and highway sway.
Versatile Multi-Size Wheel Range: Available in 13×4.5, 14×5.5, and 14×6 options to support standard highway tire sections from 175/80R13 up to 215/75R14.
Broad Multi-PCD Hub Compatibility: Features precision-punched bolt circles in 4×100, 5×114.3, and 6×139.7 to fit small European utility axles, standard 3,500-lb axles, and heavy 6-stud off-road trailer hubs.
Multiple Center Bore (CB) Configurations: Offered with 73mm, 81.5mm, 83.7mm, and 108.7mm center bores to clear grease caps, bearing protectors, and large hub snouts without binding.
Commercial-Grade Steel Construction: Stamped from high-tensile carbon steel with reinforced rim lips, resisting pothole impacts, heavy payloads, and curb scrub without rim bead deflection.
Certificates
Q1: Why is zero offset (ET 0) standard for boat trailers and caravans?
A: Zero offset positions the wheel mounting face at the exact centerline of the rim width. This keeps wheel load centered over spindle bearings, preventing extra bearing torque and maintaining uniform clearance inside trailer fenders.
Q2: How do I match the Center Bore (CB) options to my trailer axle?
A: Measure the outside diameter of your trailer hub snout or grease cap. A 73mm bore fits compact 4-stud European and mini-trailer hubs, 81.5mm to 83.7mm clears standard 5-stud 3,500-lb hubs, and 108.7mm fits 6-stud 6×139.7 Landcruiser-pattern commercial hubs.
Q3: Which tire sizes fit the 13×4.5, 14×5.5, and 14×6 rims?
A: The 13×4.5 rim fits 165R13 and 175/80R13 tires. The 14×5.5 rim is optimized for 185R14C and 195/75R14 tires. The 14×6 rim supports wider profiles including 205/75R14 and 215/75R14 trailer tires.
Q4: Are these steel wheels suitable for saltwater boat trailers?
A: Yes. ERA offers hot-dip galvanized and multi-stage powder-coated finishes that resist saltwater spray, freshwater launch submersion, and road de-icing salts without premature rusting.
Q5: What OEM and wholesale options are provided by ERA for trailer builders?
A: ERA supplies full container loads with customizable spoke patterns (modular, 8-spoke, directional), tailored finish colors (silver galvanized, gloss white, matte black), custom pallet counts, and optional pre-mounted valve stems.
