87782 ERA 205/65-10 (20.5×8.0-10) Trailer Tire and Wheel Assembly – 6 Ply Load Range C 4-Lug Powder-Coated Steel Rim Wholesale
Commercial DOT-Approved ERA 205/65-10 Low-Profile Highway Trailer Tire Pre-Mounted on 4-on-4" Steel Rim for Marine, Cargo & Camper Trailers | Direct Factory OEM & Bulk Supply
| Technical Specification | Parameters & Engineering Details |
| Brand Name | ERA |
| Tire Size Compatibility | 205/65-10 (Cross-Referenced: 20.5 × 8.0 – 10) |
| Product Type | Complete Pre-Mounted Trailer Tire & Wheel Assembly (Mounted with Valve Stem) |
| Ply Rating & Load Range | 6 P.R. (6-Ply Rated) / Load Range C (LRC) |
| Load & Speed Index | 84M (Up to 81 mph / 130 km/h Highway Service Rating) |
| Max Load Capacity | 1,100 LBS (Approx. 500 KGS) per Wheel Assembly |
| Max Operating Pressure | 50 P.S.I. Cold Inflation |
| Internal Tire Type | Tubeless (TL) Highway Trailer Tire |
| Carcass Construction | Heavy-Duty Nylon Cord Matrix: 4 Plies Tread / 2 Plies Sidewall |
| Wheel Rim Configuration | 10″ × 6″ Heavy-Gauge Steel Rim, Standard 4-Lug on 4″ PCD Bolt Circle |
| Rim Surface Finish | Anti-Corrosion Grey / White Industrial Powder Coating |
| Safety Certification | US DOT Approved (Meets Federal FMVSS Trailer Safety Regulations) |
| Target Applications | Marine Boat Trailers, Cargo/Utility Trailers, RV Campers, Heavy Jockey Dolly Wheels |
| B2B Supply Capabilities | White/Silver/Galvanized Rim Options, Custom Bolt Patterns, Palletized Export Shipping |
Turnkey Pre-Mounted Tire & Wheel Assembly: Factory balanced and mounted onto a heavy-duty 4-lug powder-coated steel rim with an installed high-pressure valve stem, saving assembly-line labor and field installation time.
Heavy-Duty 6-Ply Load Range C Rating: Engineered with a 4-ply tread and 2-ply nylon sidewall cord matrix that supports up to 1,100 lbs per wheel, providing superior puncture defense and dynamic road-shock resistance.
DOT FMVSS Certified for Legal Highway Towing: Carries full US Department of Transportation (DOT) certification and an 84M speed rating, ensuring street-legal compliance and smooth tracking at highway speeds up to 81 mph.
Low-Profile Wide Footprint Stability: The 205/65-10 (20.5×8.0-10) wide footprint delivers a low center of gravity and broad contact patch, dramatically dampening trailer sway and rut hunting under full payloads.
Marine-Grade Powder-Coated Steel Rim: Shielded with an electrostatically applied powder coat over heavy steel, protecting against coastal salt spray, freshwater ramp submersion, road de-icing salts, and UV flaking.
Certificates
Q1: What trailer applications are best suited for this ERA 205/65-10 (20.5×8.0-10) tire and wheel assembly?
A: This tire assembly is ideal for low-profile marine boat trailers, personal watercraft (PWC) haulers, pop-up tent camper trailers, light cargo/utility flatbeds, and heavy motorized jockey wheels requiring a wide, stable stance and a low ride height.
Q2: Is the 205/65-10 tire size interchangeable with 20.5×8.0-10?
A: Yes. 205/65-10 and 20.5×8.0-10 designate the same low-profile trailer tire size standard (approximately 20.5″ outer diameter, 8″ section width, and a 10″ rim fitment). They are fully interchangeable on trailers utilizing 10×6 inch rims.
Q3: What does the 84M speed and load rating mean for highway driving?
A: An 84 load index corresponds to a maximum load limit of 1,100 lbs (500 kg) per tire at 50 PSI cold. The “M” speed symbol certifies the tire for continuous legal highway travel up to 81 mph (130 km/h), exceeding older 65 mph trailer tire limits.
Q4: Will the 4-lug bolt pattern fit my trailer hub?
A: This assembly features the standard 4-lug on 4-inch pitch circle diameter (4 on 4″ PCD) bolt pattern with a standard center bore. This configuration matches most light-to-medium utility and boat trailer 2,000-lb axle hubs.
Q5: What B2B and OEM customization services are available for fleet builders from ERA?
A: ERA supplies container-load quantities with tailored options including alternative rim colors (gloss white, silver metallic, or hot-dip galvanized), custom pallet stack counts, barcode/UPC labeling, and matched spare tire mounting brackets.
